Alcatel Lucent OmniSwitch OS2260-P24 - Switch - L2+ - gestionado - 24 x 10/100/1000 (PoE+) + 4 x Gigabit SFP (uplink) - montaje en rack - PoE+ (370 W)

The Alcatel Lucent OmniSwitch OS2260-P24 is a high-performance Layer 2+ managed Gigabit Ethernet switch designed for enterprise and SMB networks. With 24 PoE+ ports and 4 Gigabit SFP uplinks, it delivers reliable power and connectivity for IP phones, cameras, and wireless access points. Its rack-mountable 1U form factor and comprehensive management features make it an ideal solution for demanding network environments.

Advantages

Power over Ethernet Plus (PoE+) with a 370 W budget simplifies deployment of powered devices. Advanced Layer 2+ features including VLAN, QoS, and link aggregation ensure efficient traffic management. Robust security with RADIUS and TACACS+ authentication protects your network. Energy-efficient Ethernet (EEE) reduces power consumption during low traffic periods.

Suitable for

• Enterprise access layer deployments
• SMB networks requiring PoE+ for IP phones and cameras
• Edge switching with uplink to core network
• Converged networks supporting voice, video, and data

Key specifications

• 24 x 10/100/1000Base-T PoE+ ports
• 4 x Gigabit SFP uplink ports
• Switching capacity: 56 Gbps
• Forwarding rate: 41.6 Mpps
• MAC address table: 8K entries
• Jumbo frame support up to 9 KB
• PoE budget: 370 W
• Management: SNMP, RMON, Telnet, HTTP, HTTPS, SSH, CLI
• Standards: IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.3ad, 802.3af, 802.3at, 802.1D, 802.1w, 802.1s, 802.1Q, 802.1p, 802.1x, 802.3az

Recommendations

For optimal performance, pair this switch with Alcatel Lucent SFP modules for uplink connectivity. Use Category 6 or higher cabling for 1 Gbps speeds. Ensure adequate ventilation in the rack to maintain operating temperature range.
