Armario de Pared 19 Pulgadas ALLNET 18U 1 Pieza Profundidad 450mm Negro Serie SMA Flat Pack

The ALLNET SMA-Series 19" wall-mounted enclosure offers a robust and secure housing solution for your network and server equipment. With 18U of rack space and a depth of 450mm, this 1-piece enclosure is ideal for smaller installations where space is at a premium. The flat pack design allows for easy transportation and assembly on-site.

Advantages

This enclosure features a lockable tempered glass front door for visibility and security, removable lockable side panels for easy access, and top/bottom cable entry with brush strips for effective cable management. The powder-coated steel construction ensures durability, while the depth-adjustable mounting rails provide flexibility for various equipment depths.

Suitable for

• Network switches, patch panels, and routers
• Small server installations
• Audio/visual equipment
• IT and telecommunications rooms

Key specifications

• Rack Units: 18U
• Form Factor: 19-inch
• External Dimensions (WxHxD): 600 x 900 x 450 mm
• Colour: Black (RAL 9005)
• Material: Steel, powder-coated
• Door: Lockable tempered glass front door
• Side Panels: Removable, lockable
• Assembly: Disassembled (Flat Pack)
• Cable Entry: Top and bottom with brush strips
• Ventilation: Passive, prepared for fan unit installation
• Load Capacity: Up to 60 kg
• Protection Class: IP20
• Mounting Rails: Two pairs of depth-adjustable 19" mounting rails
• Series: SMA-Series
• Number of Sections: 1-part (single section)

Recommendations

For optimal cable management, consider pairing this enclosure with ALLNET cable management panels and accessories. Ensure adequate ventilation if installing high-power equipment.
