Bachmann 924.067 interruptor de pedal unipolar, función de pulsación, 10 A 250 V AC, IP40, negro, 66 x 66 mm

Hands-free control is essential in many industrial and workshop environments, but finding a reliable switch that can withstand frequent use without compromising safety is a challenge. The Bachmann 924.067 foot switch solves this by offering a robust, momentary activation solution that keeps your hands free for the task at hand. With its single-pole normally open contact, it provides a simple yet effective way to control equipment, tools, or machinery with a simple press of the foot.

Who is it for

This foot switch is ideal for professionals in workshops, laboratories, and manufacturing facilities who need to operate devices without interrupting their manual work. It is suitable for controlling small machines, testing equipment, or any application where a momentary electrical contact is required. Its compact size and free-standing design make it easy to position on the floor for ergonomic access.

Main features

• Momentary switching function: activates only while pressed, returning to off when released for safe operation.
• Single-pole normally open (1 NO) contact configuration for straightforward circuit integration.
• Rated for 10 A at 250 V AC, suitable for a wide range of electrical loads.
• Durable thermoplastic housing with IP40 protection against solid objects over 1 mm.
• Compact footprint: 66 mm width and 66 mm depth, with a low profile for stable floor placement.
• Connection via screw terminals for secure and easy wiring.

Specifications

• Product type: Foot switch
• Number of poles: 1-pole
• Switching function: Momentary
• Contact configuration: 1 Normally Open (NO)
• Rated current: 10 A
• Rated voltage: 250 V AC
• Housing material: Thermoplastic
• Protection class: IP40
• Connection type: Screw terminals
• Mounting type: Floor / free-standing
• Actuation method: Foot pedal
• Operating principle: Mechanical switch
• Colour: Black
• Dimensions (W x D): 66 x 66 mm

Tips

For optimal performance, mount the foot switch on a flat, stable surface to prevent accidental movement during use. Ensure that the electrical load does not exceed the rated current and voltage to maintain safety and longevity. When wiring, use appropriate gauge wire and tighten screw terminals securely to avoid loose connections.
