Blackmagic Design Pyxis Monitor 17" Full HD IPS LCD 12G-SDI HDMI

The Blackmagic Design Pyxis Monitor is a professional 17-inch field monitor designed for filmmakers and videographers who demand accurate color and reliable monitoring on set. Featuring a Full HD IPS LCD panel with 10-bit processing, it delivers crisp images with wide 178° viewing angles. With dual 12G-SDI inputs and HDMI 2.0 connectivity, it integrates seamlessly into any professional workflow. Built-in monitoring tools including waveform, vectorscope, focus peaking, false color, and zebra ensure precise exposure and focus control. The machined aluminum chassis provides durability, while VESA mounting offers flexible rigging options.

Advantages

The Pyxis Monitor offers exceptional value with its combination of high-brightness 300 cd/m² display, comprehensive monitoring tools, and robust build quality. Its 12G-SDI inputs support up to 4K DCI 60p, making it future-proof for high-resolution productions. The built-in speakers and headphone jack provide convenient audio monitoring, and USB-C connectivity allows use as a webcam or for control.

Suitable for

• Professional film and video production
• On-set monitoring for directors and DPs
• Studio and broadcast environments
• Live event production

Key specifications

• 17" Full HD (1920x1080) IPS LCD display
• Brightness: 300 cd/m², Contrast: 1000:1
• 2 x 12G-SDI inputs, 2 x 12G-SDI loop outputs
• 1 x HDMI 2.0 input
• 10-bit processing with HDR support (HLG, PQ)
• Built-in waveform, vectorscope, histogram, focus peaking, false color, zebra
• 3D LUT support
• USB-C for webcam/control, Ethernet for control
• VESA 100x100mm mounting
• Machined aluminum chassis
• Power: 12V DC (AC adapter or external battery)

Recommendations

For professional on-set monitoring, the Blackmagic Design Pyxis Monitor is an excellent choice. Its accurate color reproduction, comprehensive toolset, and durable design make it a reliable companion for any production. Pair with a VESA mount or battery plate for maximum flexibility.
