Cable InfiniBand/fibra óptica Microconnect FIB461005 5 m LC amarillo

The Microconnect FIB461005 is a 5 m single mode fibre optic patch cable with LC connectors and OS2 fibre. With a 9 µm core diameter and yellow jacket for easy identification, this cable is designed for high-speed data transmission in enterprise networks, telecom rooms, server farms and cloud storage networks. It supports 1G/10G/40G/100G Ethernet links and low-loss transmission over long distances.

Advantages

This LC–LC OS2 single mode cable uses LSZH jacket material and conforms to common industry standards (IEC, EIA/TIA or Telcordia). The 9 µm core minimises modal dispersion and signal attenuation, allowing reliable transport of data up to 10 km at 1310 nm and up to 40 km at 1550 nm. The 5 m length and yellow colour simplify patching and cable management in racks and patch panels.

Suitable for

• Enterprise network backbone and horizontal links
• Telecom rooms and central offices
• Server farms and data centre interconnects
• Cloud storage and SAN/InfiniBand connections
• High-speed Ethernet links (1G/10G/40G/100G)

Key specifications

• Brand: MicroConnect
• Model / MPN: FIB461005
• Length: 5 m
• Connector type: LC — LC
• Fibre type: OS2 (single mode), core diameter 9 µm
• Jacket colour: Yellow
• Jacket material: LSZH
• Typical reach: up to 10 km @ 1310 nm, up to 40 km @ 1550 nm
• Weight: 0.04 kg

How to use

Inspect connectors for dust or damage before use and clean with appropriate fibre cleaning tools if necessary. Route the 5 m LC–LC patch cord between compatible LC ports in patch panels, transceivers or equipment SFP/SFP+ cages, avoiding tight bends and mechanical stress. Ensure proper strain relief and secure cable management to prevent connector or fibre damage.

Recommendations

Use this single mode LC–LC OS2 patch cable for links requiring low attenuation and long reach. Keep connectors capped when not in use, follow manufacturer cleaning procedures, and avoid bending below the specified minimum bend radius to maintain optical performance.
