Conector de red Ethernet UGREEN NW111 RJ45 Cat6 pack de 100 - plata/transparente

For installers who need a dependable, high-volume RJ45 termination solution, the UGREEN NW111 Cat6 connector pack stands out with its 50-micron gold-plated contacts and transparent polycarbonate housing that lets you visually confirm wire order before crimping. This 100-piece set is built for both solid and stranded conductors from 23AWG to 26AWG, delivering consistent performance across a wide range of Ethernet cabling jobs.

Highlights

• Cat6 rated for Gigabit and 10-Gigabit Ethernet (up to 10 Gbps, 250 MHz)
• 50-micron gold-plated phosphor bronze contacts for superior conductivity and corrosion resistance
• Transparent PC housing allows easy inspection of wire sequence before crimping
• Supports solid and stranded conductors, 23–26 AWG
• Unshielded (UTP) design for standard Cat6 UTP cable
• Durable: rated for 750 mating cycles
• Compliant with RoHS, CE, and FCC standards

In daily use

Terminating a patch panel or keystone jack becomes faster and more reliable when you can see the conductors seated correctly. The transparent body of the NW111 eliminates guesswork, reducing rework and wasted connectors. The gold-plated contacts maintain low contact resistance even after repeated insertions, ensuring stable network performance in office, home, or industrial environments. The connectors work with standard RJ45 crimp tools and are compatible with both T568A and T568B wiring schemes.

Full specifications

• Connector type: RJ45 (8P8C), unshielded
• Category rating: Cat6
• Contact plating: 50-micron gold over phosphor bronze
• Housing material: high-quality polycarbonate (PC), transparent
• Conductor compatibility: solid and stranded
• Wire gauge: 23–26 AWG
• Data rate: up to 10 Gbps (10GBASE-T)
• Bandwidth: up to 250 MHz
• Durability: 750 mating cycles
• Operating temperature: -20°C to 70°C
• Insulation resistance: >500 MΩ
• Dielectric withstanding voltage: 1000V AC RMS
• Compliance: RoHS, CE, FCC
• Pack quantity: 100 connectors

Final note

A practical bulk pack for network technicians and DIY enthusiasts who value reliability and clarity in every termination. The UGREEN NW111 combines premium materials with a transparent design that makes professional-grade connections straightforward.
