Eaton LS-11/F interruptor de final de carrera, accionador de émbolo, 1NO+1NC, 400V AC, 4A, IP67 290176

Limit switch with plunger actuator for position monitoring in industrial applications. The LS-11/F offers a snap-action contact with 1 normally open and 1 normally closed contact, rated for 400 V AC and 4 A operational current. Its IP67-rated insulated housing ensures reliable operation in demanding environments.

Advantages

High mechanical life of over 10 million operations and electrical life of over 1 million operations. The momentary plunger actuator provides precise switching. Screw terminals allow secure wiring.

Suitable for

• Machine tools
• Conveyor systems
• Automated production lines

Key specifications

• Actuator type: Plunger (momentary)
• Contact configuration: 1 NO + 1 NC
• Rated operational voltage: 400 V AC
• Rated operational current: 4 A
• Protection rating: IP67
• Housing material: Insulated plastic
• Connection: Screw terminals
• Operating temperature: -25 to +70 °C

Recommendations

For reliable position sensing in harsh industrial environments, the LS-11/F combines robust construction with long service life.
