Extensor KVM Icron Ranger 2304 transmisor y receptor

The Icron Ranger 2304 Transmitter & Receiver is a KVM extender solution designed to transmit keyboard, video and mouse signals over a wired connection up to 100 meters. The system includes a transmitter unit to connect to the source computer and a receiver unit for the remote workstation, each equipped with USB Type-A ports for peripheral connectivity. With a specified data transfer capability of 12,480 Mbit/s and support for standard AC input voltages from 100 to 240 V, the Ranger 2304 is intended for installations that require separation of user consoles from host systems while maintaining responsive control and video quality.

Advantages

The Ranger 2304 provides reliable extension of USB and video signals over long distances without the need for complex network configuration. The integrated USB Type-A ports on both transmitter and receiver simplify connection of keyboards, mice and other USB peripherals. Wide AC input compatibility allows the units to be used in various regional power environments. The grey enclosure offers unobtrusive integration into professional setups.

Suitable for

• Remote workstations in control rooms and monitoring stations
• Medical or industrial environments where equipment must be isolated from user consoles
• Corporate or educational labs requiring centralized hosts with distributed user access
• Audio-visual installations needing distance extension of input devices and video

Key specifications

• Extension distance: up to 100 meters over a wired connection
• USB interface: USB Type-A ports on both transmitter and receiver
• Data transfer rate: 12,480 Mbit/s (maximum)
• Power input: AC 100–240 V
• Colour: Grey
• Included units: Transmitter and Receiver

How to use

Connect the transmitter to the host computer using the appropriate video and USB cables, and connect the receiver to the remote monitor and USB peripherals. Link the transmitter and receiver using a suitable wired connection to reach the required distance, ensuring cable type and quality meet installation requirements. Power both units from AC supplies within the 100–240 V range. Verify video resolution and peripheral recognition on the remote workstation and adjust host or display settings if necessary.

Recommendations

For stable performance, use high-quality shielded cabling and avoid routing the connection alongside large electrical sources that may introduce interference. Confirm compatibility of connected USB devices with extender pass-through, and test the setup at intended distances prior to deployment.
