Hager FZ534N bloque de bornes de neutro 6 bornes 100A 400V gris

The Hager FZ534N is a high-quality neutral terminal block designed for use in distribution boards and consumer units. It provides a reliable and safe connection for neutral conductors in electrical installations.

Advantages

This terminal block offers robust construction with brass conductors and polyamide insulation, ensuring long-lasting performance. The screw terminals provide secure and stable connections, while the clip-on or screw-on mounting allows for flexible installation. With a rated current of 100 A and voltage of 400 V AC, it is suitable for a wide range of applications.

Suitable for

• Neutral distribution in consumer units and distribution boards
• Use with Hager enclosures and compatible systems
• Industrial and commercial electrical installations

Key specifications

• Product Type: Neutral Terminal Block
• Number of Terminals: 6 (4 small + 2 large)
• Terminal Capacity Small: 1.5 - 16 mm²
• Terminal Capacity Large: 6 - 25 mm²
• Connection Type: Screw Terminal
• Conductor Material: Brass
• Insulation Material: Polyamide (PA)
• Mounting Type: Clip-on / Screw-on
• Rated Current: 100 A
• Rated Voltage: 400 V AC
• Number of Poles: 1
• Colour: Grey
• Standard: IEC 60947-7-1
• Degree of Protection: IP20
• Operating Temperature: -25 to +70 °C
• Tightening Torque Small Terminals: 2.5 Nm
• Tightening Torque Large Terminals: 3.5 Nm

Recommendations

For optimal performance, use this terminal block with Hager distribution boards and ensure proper tightening torque as specified. Always follow local electrical codes and regulations.
