Hager LK750503 canaleta de cables de PVC para montaje en superficie 75x50mm negra 2m

Exposed cables along walls and ceilings create clutter and safety hazards. The Hager LK750503 cable duct offers a clean, protective channel for routing power and data cables indoors. Its snap-on lid allows quick access for cable changes, while the black PVC construction blends with most interiors.

Who is it for

Electricians, facility managers, and DIY installers who need a durable, surface-mounted solution for organizing cables in offices, workshops, or residential spaces.

Main features

• Material: PVC (Polyvinyl Chloride)
• Colour: Black (RAL 9005)
• Dimensions: 75 mm width x 50 mm height x 2000 mm length
• Single compartment with snap-on lid
• Surface mounted
• Halogen-free: No
• Temperature range: -5°C to +60°C
• Impact resistance: IK07
• Self-extinguishing according to EN 60695-2-11 (glow-wire test 850°C)
• Usable cross-sectional area: approx. 30 cm²

Specifications

• Brand: Hager
• Model: LK750503
• MPN: LK750503
• EAN: 4012740104630
• Material: PVC
• Colour: Black
• Width: 75 mm
• Height: 50 mm
• Length: 2000 mm
• Mounting type: Surface mounted
• Number of compartments: 1
• Lid type: Snap-on / Clip-on
• Halogen-free: No
• IP protection class: IP40
• Temperature range: -5°C to +60°C
• Fire behaviour: Self-extinguishing according to EN 60695-2-11 (glow-wire test 850°C)
• Impact resistance: IK07
• Standards compliance: EN 50085-1, EN 50085-2-1
• Usable cross-sectional area: approx. 30 cm²
• Application area: Indoor cable management for power and data cables
• UV resistant: No

Tips

For a neat installation, cut the duct with a fine-tooth saw and deburr edges. Use appropriate screws or adhesive for mounting depending on the surface. The snap-on lid can be painted to match wall colour if desired.
