HellermannTyton Soporte autoadhesivo para bridas 19x19 mm blanco PA66 (pack de 100) 308-31203

Self-adhesive cable tie mount for secure, tool-free fastening of cable ties on flat indoor surfaces. The synthetic rubber adhesive bonds firmly to clean, dry substrates, providing a reliable anchor point without drilling.

Advantages

Compact 19 x 19 mm footprint with a low 4.3 mm profile keeps installations neat. Made from halogen-free polyamide 6.6, the mount is robust and meets UL94 V2 flammability requirements. The adhesive is effective from -20 °C to +65 °C, while the mount itself withstands -40 °C to +85 °C.

Suitable for

• Securing cable ties up to 3.6 mm wide in indoor cable management
• Mounting on smooth, flat surfaces such as panels, enclosures, and walls
• Organising wiring in control cabinets, offices, and residential installations

Key specifications

• Material: Polyamide 6.6 (PA66)
• Colour: White
• Dimensions (L x W x H): 19 x 19 x 4.3 mm
• Max. cable tie width: 3.6 mm
• Operating temperature: -40 °C to +85 °C
• Adhesive temperature range: -20 °C to +65 °C
• Flammability rating: UL94 V2
• Adhesive type: Synthetic rubber
• Pack quantity: 100 pieces

Recommendations

For best adhesion, clean the mounting surface with isopropyl alcohol and allow to dry before applying. Press firmly for a few seconds and wait 24 hours before loading the mount with cable ties.
