MENNEKES 18662 Medidor de energía Modbus TCP para gestión de cargas, 3 fases 80A, MID Clase B, carril DIN

Direct measurement up to 80 A on a 3-phase 4-wire network, with Modbus TCP over Ethernet and MID Class B accuracy — the MENNEKES 18662 brings precise energy data straight into your load management system.

Overview

The MENNEKES 18662 is a DIN rail-mounted energy meter engineered for load management and sub-metering in industrial and commercial installations. It measures active and reactive energy, power, voltage, current, frequency, and power factor on three-phase systems up to 3x230/400 V AC. Data is transmitted via Modbus TCP over a standard RJ45 Ethernet port, enabling seamless integration with PLCs, building management systems, and energy monitoring platforms.

What stands out

• Direct 80 A measurement — no external current transformers required, simplifying installation and reducing cost.
• MID compliant (EN 50470-1/3) with Class B accuracy for active energy, ensuring billing-grade precision.
• Modbus TCP interface for real-time data access, multi-tariff support, and remote configuration.
• Backlit LCD display for on-site reading of all key electrical parameters.
• Compact 4-module (4TE) DIN rail housing with IP51 front protection, suitable for distribution boards.
• Configurable S0 pulse output for integration with legacy systems or additional monitoring.

Technical details

• Measurement type: 3-phase, 4-wire
• Voltage rating: 3x230/400 V AC
• Frequency: 50/60 Hz
• Maximum current (Imax): 80 A
• Start current (Ist): 20 mA
• Accuracy class active energy: Class B (EN 50470-3)
• Accuracy class reactive energy: Class 2
• Communication: Modbus TCP (Ethernet RJ45)
• Measured parameters: Active energy (kWh), reactive energy (kvarh), active power (kW), reactive power (kvar), apparent power (kVA), voltage (V), current (A), frequency (Hz), power factor
• Tariff support: Multi-tariff capable via Modbus
• Pulse output: S0 (configurable)
• Mounting: DIN rail, 4 modules (4TE)
• Display: Backlit LCD
• Protection class: IP51 (front), IP20 (terminals)
• Operating temperature: -25°C to +55°C
• Power consumption: < 2 W / 10 VA per phase
• Housing material: Self-extinguishing polycarbonate
• MID compliant: Yes (EN 50470-1/3)

Our verdict

For facilities that need reliable, MID-compliant energy data with straightforward network integration, the MENNEKES 18662 delivers. Its direct 80 A capability and Modbus TCP connectivity make it a practical choice for load management and sub-metering without the complexity of external CTs.
