METZ CONNECT RKAk-E10 relé de potencia 24 V DC 16 A 1 conmutador verde 110304412008

In industrial control panels and building automation systems, the METZ CONNECT RKAk-E10 power relay reliably switches high-current loads up to 16 A. Its compact PCB-mount design with a single changeover contact makes it a practical choice for HVAC controllers, lighting systems, and motor controls where space is limited and dependable performance is essential.

Key specifications

• Coil voltage: 24 V DC
• Contact configuration: 1 changeover (1 CO / 1 PDT)
• Rated switching current: 16 A
• Rated switching voltage: 250 V AC
• Coil power: 0.53 W
• Coil resistance: 1090 Ohm
• Contact material: AgNi (Silver Nickel)
• Dielectric strength coil/contact: 5000 V AC
• Dielectric strength open contact: 1000 V AC
• Insulation resistance: > 100 MOhm
• Operating temperature range: -40 °C to +85 °C
• Mounting type: PCB mount (THT)
• Electrical life: 100,000 cycles at rated load
• Mechanical life: 10,000,000 cycles
• Protection class: RT II (Flux Proof)
• Colour: Green
• Approvals: VDE, UL, CSA

Why choose it

This relay combines high switching capacity with low coil power consumption, reducing heat generation and energy use in your control circuits. The AgNi contacts ensure reliable switching even under demanding conditions, while the flux-proof housing protects against contamination during soldering and operation. Its wide temperature range makes it suitable for both indoor and harsh environments.

Ideal use cases

• HVAC and building automation systems
• Industrial control panels and PLC outputs
• Lighting and motor control circuits
• Appliance controls requiring 16 A switching

Good to know

The RKAk-E10 is a PCB relay, so it is soldered directly onto a printed circuit board. Ensure proper heat management during soldering and verify that the coil voltage matches your control signal. The green colour aids in visual identification, and the relay is approved by VDE, UL, and CSA for global compliance.
