MikroTik RouterBOARD FTC - Convertidor de medios - 1GbE - 10Base-T, 100Base-TX, 1000Base-T, 1000Base-X - RJ-45 / SFP (mini-GBIC)

The MikroTik RouterBOARD FTC is a compact and robust fiber-to-copper media converter designed to bridge 10/100/1000Base-T Ethernet networks with 1000Base-X fiber optic networks. Featuring a single RJ-45 port and an SFP cage, this device enables seamless integration of fiber infrastructure into existing copper-based LANs, extending network reach up to several kilometers depending on the SFP module used. Powered by a QCA9531 CPU and running RouterOS Level 3, it offers advanced routing and management capabilities in a small form factor.

Advantages

Reliable media conversion with support for jumbo frames up to 10218 bytes ensures efficient data transfer. The wide input voltage range (12-57 V DC) and passive PoE support provide flexible powering options, making it suitable for remote installations. With an industrial temperature range of -40°C to 70°C, the FTC performs reliably in harsh environments. Its desktop and wall-mountable design allows for easy deployment in space-constrained locations.

Suitable for

• Extending network reach beyond 100 meters using fiber optic cabling
• Connecting remote offices or devices in industrial settings
• Integrating fiber backbone with copper access networks
• Applications requiring robust performance in extreme temperatures

Key specifications

• Ethernet Port: 1x 10/100/1000Base-T RJ-45 with Auto MDI/MDIX
• Fiber Port: 1x 1000Base-X SFP slot (mini-GBIC)
• Data Rate: 1 Gbps
• Standards: IEEE 802.3, 802.3u, 802.3ab, 802.3z
• Jumbo Frame Support: Up to 10218 bytes
• Power Input: 12-57 V DC via DC jack or Passive PoE
• Max Power Consumption: 5 W
• Operating Temperature: -40°C to 70°C
• Enclosure: Plastic, desktop/wall-mountable
• CPU: QCA9531 850 MHz
• RAM: 64 MB
• Storage: 16 MB Flash
• OS: RouterOS Level 3
• LED Indicators: Power, Ethernet Link/Activity, SFP Link/Activity

Recommendations

For optimal performance, use a compatible SFP module (sold separately) that matches your fiber type and distance requirements. The FTC is ideal for network engineers seeking a cost-effective, high-reliability media converter for enterprise or industrial deployments.
