Montolit FSB06 fresa de metal duro 6 mm fresa en seco/húmedo Mondrillo Black

Milling hard materials like steel and stainless steel demands a cutter that stays sharp and precise under both dry and wet conditions. The Montolit FSB06 Mondrillo Black solid carbide end mill delivers reliable slotting, profiling, and general-purpose milling with a 6 mm cutting diameter and a robust 4-flute design. Its solid carbide construction and 30° helix angle ensure efficient chip evacuation and smooth cutting action, while the uncoated surface maintains a clean finish on a variety of metals.

Who is it for

This end mill is built for machinists, metalworkers, and fabricators who need a dependable tool for everyday milling tasks on steel, stainless steel, cast iron, and non-ferrous metals. Whether you are working on a CNC machine or a manual mill, the FSB06 offers consistent performance in both dry and wet cutting environments, making it a versatile addition to any workshop.

Main features

• Solid carbide (HM) construction for high wear resistance and long tool life
• 4-flute center-cutting geometry for efficient plunging and slotting
• 30° helix angle optimizes chip flow and reduces cutting forces
• Suitable for dry and wet milling applications
• Cylindrical shank with h6 tolerance for secure and accurate clamping
• Manufactured to DIN 6527 K standard for consistent quality
• Black finish for easy identification and corrosion resistance

Specifications

• Cutting diameter (D1): 6 mm
• Shank diameter (D2): 6 mm
• Cutting length (L1): 15 mm
• Overall length (L2): 57 mm
• Number of flutes: 4
• Helix angle: 30°
• Corner type: Square end
• Coating: Uncoated
• Shank type: Cylindrical
• Shank tolerance: h6
• Cutting edge geometry: Center cutting
• Manufacturing standard: DIN 6527 K
• Application materials: Steel, stainless steel, cast iron, non-ferrous metals
• Recommended use: General purpose milling, slotting, profiling
• Country of origin: Italy

Tips

For best results, use appropriate cutting speeds and feeds based on the workpiece material and machine rigidity. Always secure the tool properly in a collet or holder with the correct shank diameter. When milling dry, consider air blast or vacuum to clear chips; for wet milling, use a suitable coolant to extend tool life. Store the cutter in a dry place to prevent corrosion.
