Placa de montaje Rittal 8617.530 para racks, acero galvanizado, 500×500 mm, 2,5 mm

Rittal 8617.530 is a galvanized steel mounting plate designed for use inside server and network racks and enclosures. With overall dimensions of 500 × 500 mm and a material thickness of 2.5 mm, the grey plate provides a flat, rigid surface for securing equipment, modules or custom fixtures. Supplied as a single piece, it is intended to be fitted to rack interiors to create a stable internal mounting area for industrial control components, power distribution units, patch panels or bespoke assemblies.

Advantages

The mounting plate is manufactured from corrosion-resistant galvanized steel for increased durability in industrial and IT environments. Its 2.5 mm material thickness offers a balance of stiffness and workability, allowing for cutting or drilling if additional holes or cutouts are required for cable routing or component brackets. The 500 × 500 mm size fits common rack and enclosure mounting patterns and gives a uniform internal surface for reliable fastening of equipment.

Suitable for

Key specifications

How to use

Position the mounting plate inside the rack or enclosure at the desired height and mark fixing points on the rack profile. Secure the plate using appropriate fasteners compatible with the rack system and the plate thickness; ensure fasteners are tightened to provide a firm, vibration-resistant attachment. If additional holes or cutouts are required, mark and process them before final installation using suitable metalworking tools and following safety precautions for cutting galvanized steel.

Recommendations

For best results, use stainless-steel or zinc-plated fasteners to avoid galvanic corrosion between the plate and mounting hardware. When drilling or cutting, deburr edges and apply corrosion protection to exposed bare metal. Verify weight and load distribution for heavy components to ensure the rack and fixing points can support the intended equipment.
