Portátil MSI Katana 15 HX B14WFK-020XPL — 15,6 inch QHD 165 Hz, Intel Core i7-14650HX, 16 GB DDR5, 512 GB NVMe, NVIDIA RTX 5060 8 GB, compatible con Windows

The MSI Katana 15 HX B14WFK-020XPL is a 15.6" laptop with a 2560×1440 (QHD) IPS‑Level display at 165 Hz and 100% DCI‑P3 coverage. It is equipped with an Intel Core i7‑14650HX processor (16 cores, up to 5.2 GHz), 16 GB DDR5 memory (2×8 GB, upgradable to 96 GB), a 512 GB NVMe PCIe 4.0 SSD, and a discrete NVIDIA GeForce RTX 5060 graphics card with 8 GB GDDR7 memory. The laptop supports Wi‑Fi 6E, Bluetooth 5.3, Ethernet, HDMI 2.1 and USB‑C with DisplayPort Alt Mode. The device includes a 75 Wh battery and a 240 W AC adapter, and features a 4‑zone RGB backlit keyboard and integrated audio with NAHIMIC 3.

Advantages

The combination of a high‑refresh‑rate QHD display (165 Hz) with wide DCI‑P3 colour coverage and an NVIDIA GeForce RTX 5060 GPU provides balanced performance for gaming and content creation. The Intel 14th‑generation i7‑14650HX offers multiple high‑performance and efficient cores, supporting demanding multitasking and burst workloads. DDR5 memory and PCIe 4.0 NVMe storage deliver faster data access and responsiveness. Built‑in Wi‑Fi 6E, Bluetooth 5.3 and a full set of modern ports (HDMI 2.1, USB‑C DP Alt, RJ‑45) ensure versatile connectivity. The 75 Wh battery and included 240 W charger supply sustained power for intensive use.

Suitable for

• High‑frame‑rate gaming at QHD resolution
• Photo and video editing, colour‑accurate content work
• Multitasking and software development
• Mobile work requiring wired and wireless connectivity

Key specifications

• Display: 15.6" (39.6 cm) IPS‑Level, 2560×1440 (QHD), 165 Hz, 300 cd/m², anti‑glare, 100% DCI‑P3
• Processor: Intel Core i7‑14650HX, 16 cores (8 performance + 8 efficient), up to 5.2 GHz boost, 30 MB Smart Cache, base power 55 W, max turbo power 157 W
• Graphics: NVIDIA GeForce RTX 5060 with 8 GB GDDR7; integrated Intel UHD Graphics
• Memory: 16 GB DDR5‑5600 (2×8 GB), 2x SO‑DIMM slots, upgradable to 96 GB
• Storage: 512 GB NVMe PCIe 4.0 SSD, M.2 form factor, NVMe support
• Battery: 75 Wh, 4‑cell
• Ports: HDMI 2.1 (1), USB‑C with DisplayPort Alt Mode (1), USB 3.2 Gen 2 Type‑A (3), combo headphone/mic jack, RJ‑45 Ethernet
• Networking: Wi‑Fi 6E (Intel AX211), Bluetooth 5.3, Gigabit Ethernet
• Audio & camera: NAHIMIC 3 audio, 2× speakers, built‑in microphone, front camera 1280×720 @30 fps
• Physical: Weight 2.4 kg, dimensions 359 × 262 × 25.5 mm, colour: black
• Security: TPM 2.0
• Power delivery: USB Power Delivery supported, 240 W AC adapter included

How to use

Power on the laptop using the main power button and connect the included 240 W AC adapter for full performance during gaming or heavy workloads. Use the operating system setup to configure user accounts and network connections (Wi‑Fi 6E or Ethernet). Install required drivers and software for the NVIDIA GPU and Intel components to ensure optimal performance. Memory can be expanded by accessing the two SO‑DIMM slots and replacing or adding compatible DDR5 modules; storage can be upgraded via the M.2 PCIe slot. Adjust display refresh rate and GPU settings in system or gaming software according to your workload.

Recommendations

For sustained gaming and content creation sessions, keep the AC adapter connected to maintain peak CPU/GPU performance. Use up to the supported DDR5‑5600 memory and NVMe PCIe 4.0 storage for best responsiveness. Follow local regulations for battery disposal and avoid disposing of the device in household waste.
