RUKO MGR-DIN357-M12x1,75mm abrazadera en U, acero inoxidable A2, rosca M12, 60mm de ancho interior, 100mm de longitud de brazo

U-bolt made of A2 stainless steel with M12 thread and 1.75 mm pitch, featuring high corrosion resistance for demanding environments. The bright, natural finish and robust construction ensure reliable fastening in indoor, outdoor, marine, and industrial applications.

Advantages

A2 stainless steel (AISI 304) provides excellent corrosion resistance and good chemical resistance against many chemicals, though not suitable for strong acids or chlorides. The material is non-magnetic or weakly magnetic, and the tensile strength class A2-70 (700 N/mm²) guarantees high load capacity. The U-bolt is designed for threaded fastening with M12 nuts and washers (not included).

Suitable for

• Indoor and outdoor fastening applications
• Marine environments requiring corrosion resistance
• Industrial installations with high mechanical stress
• Securing pipes, cables, and other components

Key specifications

• Standard: DIN 357
• Thread diameter: M12
• Thread pitch: 1.75 mm
• Inner width (b): 60 mm
• Leg length (h1): 100 mm
• Rod diameter (d): 12 mm
• Overall height (L): 106 mm
• Overall width (W): 84 mm
• Material: A2 stainless steel (AISI 304)
• Surface finish: Bright / Natural
• Tensile strength class: A2-70 (700 N/mm²)

Recommendations

Use with M12 nuts and washers (not included) for secure installation. Ensure the thread is properly engaged and tightened to the recommended torque. For optimal corrosion resistance, avoid contact with strong acids or chlorides.
