RUKO SMU-DIN382-M14x2,0mm-6k Terraja, rosca métrica gruesa, HSS, 38 mm de diámetro exterior

Machinists and metalworkers cutting external M14 threads with a 2.0 mm pitch will find the RUKO GMBH SMU-DIN382-M14x2.0mm-6k round die a dependable tool for both manual and machine operations. Manufactured from high-speed steel, this die is built to handle unalloyed and low-alloyed steels, non-ferrous metals, and plastics.

Key specifications

• Thread type: Metric coarse thread
• Nominal thread diameter: M14
• Thread pitch: 2.0 mm
• Tolerance class: 6k
• Material: HSS (high-speed steel)
• Outer diameter: 38 mm
• Thickness: 10 mm
• Cutting direction: Right-hand
• Number of flutes: 4
• Manufacturing process: Ground thread
• Surface finish: Bright (uncoated)

Why choose it

The die conforms to DIN 382, ensuring standardized dimensions and reliable thread quality. Its HSS construction provides good wear resistance, making it suitable for repeated threading tasks in workshop environments.

Ideal use cases

• Creating external threads on rods and bolts
• Repairing damaged threads on M14 fasteners
• Threading non-ferrous metal components
• Plastic part threading where metal dies are required

Good to know

The die is designed for right-hand threads, the most common thread orientation. Its 38 mm outer diameter fits standard die holders for manual or machine use.
