SATEL DS-T1 Sensor de temperatura digital para GPRS-A

The SATEL DS-T1 is a digital temperature sensor designed for seamless integration with SATEL GPRS-A, GPRS-A LTE, ETHM-A, INT-GSM, and INT-GSM LTE modules. It provides accurate temperature monitoring for indoor environments, making it an essential component for alarm and automation systems.

Advantages

High accuracy of ±0.5°C in the standard range (-10°C to +60°C) and ±1°C in the extended range (-35°C to -10°C, +60°C to +70°C). The sensor uses a dedicated 1-Wire bus for reliable communication and comes with a 3-meter cable for flexible installation. Its low power consumption (max. 10 mA) and 12V DC power supply from the connected module ensure energy efficiency.

Suitable for

• Environmental temperature monitoring in residential and commercial buildings
• Integration with SATEL alarm and automation systems
• Indoor surface-mount installations

Key specifications

• Sensor Type: Digital
• Measurement Range: -35°C to +70°C
• Accuracy: ±0.5°C (-10°C to +60°C), ±1°C (extended)
• Interface: Dedicated 1-Wire Bus (Satel)
• Cable Length: 3 meters
• Power Supply: 12V DC (from connected module)
• Current Consumption: Max. 10 mA
• Enclosure Material: Plastic
• Application Environment: Indoor
• Installation Type: Surface Mount

Recommendations

For optimal performance, use the DS-T1 with compatible SATEL modules. Ensure proper surface mounting and avoid exposure to extreme conditions beyond the specified range.
