Switch Gigabit PoE L2 gestionado SonicWall SWS14-24FPOE — 24x Gigabit (10/100/1000), 1U, consola RJ-45

SonicWall SWS14-24FPOE is a managed Layer 2 gigabit Ethernet switch that provides 24 RJ-45 ports with auto-sensing 10/100/1000 Mbps connectivity and integrated Power over Ethernet (PoE) support. Designed for rack mounting in a 1U chassis, the switch delivers a switching capacity of 128 Gbit/s and maintains a 32,000-entry MAC address table. It includes an RJ-45 console port and supports industry standards including IEEE 802.1ab, 802.1p, 802.1x and PoE standards IEEE 802.3af/at. The SonicWall SWS14-24FPOE is intended to serve small and medium business networks and is compatible with deployments that require IP phones, wireless access points and surveillance cameras.

Advantages

The managed Layer 2 architecture enables VLANs, QoS and access control features appropriate for segmented networks and prioritized traffic. With 24 gigabit RJ-45 ports and PoE support, the switch can power edge devices directly, reducing the need for separate power supplies. A 1U rack-mountable form factor conserves rack space while providing enterprise-oriented switching capacity. Compliance with common IEEE standards ensures interoperability with existing network equipment and straightforward integration into SonicWall-managed environments.

Suitable for

Key specifications

How to use

Install the SonicWall SWS14-24FPOE in a standard 19-inch equipment rack using the included rack-mount brackets. Connect uplink links and edge devices to the gigabit RJ-45 ports; the switch will negotiate link speeds automatically. Configure management settings via the console port or the supported management interface to define VLANs, QoS, PoE provisioning and access control policies. Ensure PoE budget planning by verifying power requirements of connected devices and configuring port-level PoE settings where applicable.

Recommendations

For reliable operation, place the switch in a temperature-controlled environment with appropriate ventilation. Plan PoE power allocation before deployment to avoid exceeding the device’s available PoE budget. Use VLANs and QoS to separate voice, video and data traffic for consistent performance, and integrate the switch into existing SonicWall management tools for centralized configuration and monitoring.
