VOLTCRAFT MP-4 conector banana de 4 mm, recto, conexión por tornillo, rojo, 50 uds. VC-17002935

In electronics labs and test environments, unreliable connections can lead to inaccurate measurements and frustrating downtime. The VOLTCRAFT MP-4 4 mm banana plug with clamp terminal solves this by providing a secure, low-resistance connection for your test leads and cables. This straight plug features a nickel-plated brass contact for excellent conductivity and a robust polyamide insulation that withstands daily use. The screw clamp termination accepts wires up to 2.5 mm², making it ideal for building custom test leads, patch cords, and connecting to power supplies, multimeters, and other equipment with 4 mm sockets. Rated for up to 32 A and 60 V DC, it handles a wide range of low-voltage applications. Supplied in a pack of 50 red plugs, it's perfect for labs, workshops, and educational institutions that need reliable, high-quality connectors in bulk.

Who is it for

This product is intended for electronics engineers, technicians, hobbyists, and educators who need to create or repair test leads and connections in laboratory, service, or educational settings. It is especially useful for those who require a dependable, high-current 4 mm plug that can be easily assembled without soldering.

Main features

• 4 mm banana plug with straight design for easy insertion into standard sockets
• Screw clamp terminal for quick, solderless connection of wires up to 2.5 mm²
• Nickel-plated brass contact ensures low contact resistance and long-term reliability
• Durable polyamide insulation provides electrical safety and mechanical strength
• High current rating: up to 32 A, suitable for demanding test setups
• Pack of 50 red plugs offers excellent value for bulk use

Specifications

• Connector type: 4 mm banana plug
• Connector design: straight
• Connection type: clamp terminal (screw)
• Pin diameter: 4 mm
• Colour: red
• Max. current rating: 32 A
• Max. voltage rating: 60 V DC
• Contact material: brass, nickel-plated
• Insulation material: polyamide (PA)
• Max. cable cross-section: 2.5 mm²
• Operating temperature range: -25 °C to +70 °C
• Overall plug length: 55 mm
• Packaging quantity: 50 pieces
• Product series: MP-4

Tips

To ensure a reliable connection, strip the wire to the recommended length (typically 8–10 mm) and tighten the clamp screw firmly. For applications requiring frequent connection/disconnection, consider using a plug with a retractable sleeve or a right-angle design. Always verify that the current and voltage ratings match your application to avoid overheating or damage.
