2-power 2P-LTN156AT33-401 - 39,6 cm (15,6")

A cracked or dim laptop display can render your entire machine unusable, but replacing the panel yourself is often far cheaper than buying a new laptop. The 2-POWER 2P-LTN156AT33-401 is a direct replacement for the Samsung LTN156AT33 15.6-inch screen, giving you a clear, bright image without the hassle of compatibility guesswork.

Who is it for

This panel is ideal for DIY repair enthusiasts, IT technicians, and anyone who needs to restore a laptop with a failed 15.6-inch WXGA display. If your original screen is cracked, has dead pixels, or suffers from backlight failure, this replacement will bring your device back to life.

Main features

• 15.6-inch diagonal (39.6 cm) with a 16:9 aspect ratio, perfect for everyday productivity and media consumption.
• WXGA HD resolution (1366 x 768) delivers sharp text and vibrant images for a crisp viewing experience.
• LED backlighting provides consistent brightness and energy efficiency, with a typical brightness of 220 cd/m².
• Glossy surface finish enhances color saturation and contrast, making visuals pop.
• TN (Twisted Nematic) panel technology offers fast response times (~8 ms grey-to-grey) and low power consumption (~5W).
• 40-pin LED connector located on the bottom left ensures straightforward installation in compatible laptops.
• Compatible with Samsung LTN156AT33 and equivalent models, ensuring a precise fit and reliable performance.

Specifications

• Brand: 2-POWER
• Model: 2P-LTN156AT33-401
• Screen Size: 15.6 inches (39.6 cm)
• Display Resolution: 1366 x 768 (WXGA HD)
• Backlight Technology: LED
• Aspect Ratio: 16:9
• Surface Finish: Glossy
• Data Connector: 40-pin LED (bottom left)
• Refresh Rate: 60 Hz
• Panel Type: TN (Twisted Nematic)
• Display Technology: TFT Active Matrix LCD
• Pixel Density: ~100 PPI
• Response Time: ~8 ms (Grey-to-Grey)
• Brightness: ~220 cd/m² (nits)
• Color Gamut: ~45% NTSC
• Viewing Angle (H/V): ~45°/45°/20°/45° (L/R/U/D)
• Power Consumption: ~5W
• Condition: New
• Original Panel Manufacturer (Compatible): Samsung (for LTN156AT33)
• Product Type: Laptop LCD Display Panel
• Mounting Type: Screw-in (bare panel)

Tips

Before ordering, double-check your laptop's exact screen model and connector position. The 40-pin connector on this panel is located on the bottom left, so verify that your original screen matches this layout. Handle the panel by its edges to avoid fingerprints or pressure damage, and test the screen before fully reassembling your laptop.
