ABB SZ-BSK5 Cubierta de protección contra contactos para peines de fases, gris GHV0360505R0001

Electricians and panel builders working with ABB phase busbars need reliable protection against accidental contact with live parts. The ABB SZ-BSK5 touch protection cap clips onto the busbar to cover exposed sections, reducing the risk of electric shock during installation and maintenance. Its grey thermoplastic body blends with standard distribution board components.

Key specifications

• Material: Thermoplastic, halogen-free and self-extinguishing
• Colour: Grey
• Mounting: Clip-on / snap-on
• Module width covered: 0.5 modules (approx. 9 mm)
• Flammability rating: UL 94 V-0
• Operating temperature range: -25°C to +70°C

Why choose it

This cap is designed specifically for ABB busbars, ensuring a secure fit and reliable insulation. The halogen-free material reduces toxic smoke emissions in case of fire, and the self-extinguishing property limits flame spread. Its compact size covers half a module width, making it suitable for tight installations.

Ideal use cases

• Covering unused busbar sections in distribution boards
• Protecting against direct contact during maintenance
• Retrofitting existing ABB busbar systems

Good to know

The cap is compliant with IEC 60947-7-1 for busbar accessories and meets RoHS requirements. It can be stored in temperatures from -40°C to +80°C.
