ABB Ty-Rap Brida TY29M 771x6,9 mm natural (pack de 50 unidades)

The ABB Ty-Rap Cable Tie TY29M is a high-performance, general-purpose cable tie designed for reliable bundling and fastening of wires and cables. Manufactured from durable Nylon 6.6, this natural-coloured tie offers excellent tensile strength and a wide operating temperature range, making it suitable for various industrial and commercial applications. Each pack contains 50 ties, each measuring 771 mm in length and 6.9 mm in width, capable of securing bundles up to 229 mm in diameter.

Advantages

• High tensile strength of 534 N (120 lbs) ensures secure fastening.
• Stainless steel barb locking mechanism provides reliable, permanent hold.
• UL 94 V-2 flammability rating for safety in electrical environments.
• Halogen-free and RoHS compliant, supporting environmental and health standards.
• Wide operating temperature range (-40°C to +85°C) for versatile use.

Suitable for

• General cable bundling and fastening in electrical installations
• Industrial wiring and panel building
• Automotive and aerospace harness assembly
• Data center and telecommunications cable management

Key specifications

• Product Type: Standard Cable Tie
• Series: Ty-Rap
• Material: Nylon 6.6
• Colour: Natural
• Length: 771 mm
• Width: 6.9 mm
• Maximum Bundle Diameter: 229 mm
• Tensile Strength: 534 N
• Operating Temperature: -40°C to +85°C
• Flammability Rating: UL 94 V-2
• Locking Mechanism: Stainless Steel Barb
• Quantity per Pack: 50

Recommendations

For optimal performance, ensure the cable tie is not over-tightened beyond the recommended tensile strength. Store in a cool, dry place away from direct sunlight to preserve material integrity. Suitable for indoor use; limited UV resistance for natural nylon.
