Abrazadera de tubo con cinta DEHN 540821 D 6 mm-3/4 con conexión M8 (540821)

Band pipe clamp for secure fastening of pipes, cables, and conduits, featuring a single-screw design for quick installation and an M8 internal thread for direct mounting to threaded rods or bolts.

Advantages

Electro-galvanized steel construction provides reliable corrosion protection for indoor dry environments. The slotted head screw with combination cross-slot (PZ2/Slotted) allows tool flexibility during installation.

Suitable for

• Pipes with diameter 6–22 mm (1/4–7/8 inch)
• Indoor applications in dry areas (corrosion class C1/C2)
• Mounting to M8 threaded rods or compatible fasteners

Key specifications

• Material: Steel DD11 (EN 10111), electro-galvanized (min. 5 µm zinc)
• Band width: 12 mm, thickness: 0.8 mm
• Connection thread: M8 internal
• Max. recommended load: 0.5 kN
• Temperature resistance: -30°C to +100°C

Recommendations

For reliable pipe fastening in dry indoor installations, pair with an M8 threaded rod or bolt. Ensure pipe diameter falls within the specified range for optimal clamping force.
