ABUS TVCC34011 minicámara tipo ojo de pez – 420 TVL día/noche interior/exterior CCTV

Discreet surveillance in tight spaces often means compromising on image quality or durability. The ABUS TVCC34011 mini cone camera solves this by packing a 1/3" CCD sensor and pinhole lens into a compact metal housing just 20 mm in diameter. Whether you need to monitor a doorway, shelf, or small room, this camera delivers clear colour video at 420 TVL resolution, even in low light down to 0.5 lux. Its threaded M12 mounting and integrated 0.5 m cable make installation straightforward in both indoor and protected outdoor locations.

Who is it for

This camera is ideal for homeowners, retail staff, or small business owners who need an unobtrusive yet reliable security solution. If you want to keep an eye on a cash register, entrance, or narrow corridor without bulky equipment, the TVCC34011 fits the bill. It works with any standard analogue CCTV system (PAL) and requires only a 12 V DC power supply, making it easy to integrate into existing setups.

Main features

• Mini cone design with 20 mm diameter for covert installation
• 1/3" CCD sensor with 420 TVL resolution for sharp colour images
• Pinhole lens with 3.7 mm focal length and approx. 90° horizontal field of view
• Low-light sensitivity: 0.5 lux @ F1.2 for day/night use
• Durable metal housing for indoor and protected outdoor use
• Threaded M12 mounting for secure placement
• Integrated 0.5 m cable with BNC video output
• Low power consumption: max 100 mA at 12 V DC

Specifications

• Sensor: 1/3" CCD
• Resolution: 420 TVL
• Lens: Pinhole, 3.7 mm
• Horizontal field of view: approx. 90°
• Minimum illumination: 0.5 lux @ F1.2
• Video output: BNC composite, PAL signal
• Power supply: 12 V DC, max 100 mA
• Operating temperature: -10°C to +50°C
• Housing: Metal
• Dimensions (body): Ø 20 x 20 mm
• Cable length: approx. 0.5 m

Tips

For best results, position the camera at eye level or slightly above to capture faces clearly. Avoid pointing it directly at bright light sources to prevent glare. Since the camera is not weatherproof, install it under an eave or canopy if used outdoors. Pair it with a 12 V DC power supply (not included) and a compatible DVR for recording.
