ACAR PZ-4Z/OTM H05VV-F 3G1.0 alargador enrollable de 20m con protección térmica, 4 tomas Schuko, 230V/10A, IP20, negro/naranja

Running out of reachable power outlets in a workshop, garage, or during indoor projects often means juggling multiple short cords or dangerously overloading a single socket. The ACAR PZ-4Z/OTM retractable extension cable solves this by delivering 20 metres of robust H05VV-F cable on a compact reel with four Schuko sockets, all protected by an integrated thermal cut-out that prevents overheating when the cable is fully wound.

Who is it for

This extension reel is ideal for DIY enthusiasts, electricians, and maintenance staff who need a reliable, portable power source for power tools, lighting, and appliances in indoor or weather-protected environments. Its retractable design keeps the cable tidy and tangle-free, while the sturdy housing with carry handle makes it easy to move between work areas.

Main features

• 20 m H05VV-F cable with 3G1.0 mm² conductors (phase, neutral, earth) for safe and flexible power delivery.
• Four Schuko (Type F) sockets allow simultaneous connection of multiple devices.
• Thermal cut-out (OTM) automatically disconnects power if the reel overheats, especially when cable is wound.
• Rated for 230V AC; maximum current 10 A (unwound) / 4.3 A (wound), supporting up to 2300 W / 1000 W respectively.
• High-impact plastic housing in black/orange for durability and visibility.
• IP20 rating – suitable for indoor use and protected outdoor areas.
• Integrated carry handle and retractable mechanism for effortless cable management.

Specifications

• Brand: ACAR
• Model: PZ-4Z/OTM
• MPN: M02047
• EAN: 5901791900362
• Cable Length: 20 m
• Cable Type: H05VV-F
• Conductor Configuration: 3G1.0 mm² (3 conductors, 1.0 mm² cross-section, with earth)
• Number of Sockets: 4
• Socket Type: Schuko (Type F)
• Plug Type: Schuko (Type F)
• Rated Voltage: 230V AC
• Max Current (Unwound): 10 A
• Max Power (Unwound): 2300 W
• Max Current (Wound): 4.3 A
• Max Power (Wound): 1000 W
• Overload Protection: Thermal Cut-out (OTM)
• Ingress Protection (IP) Rating: IP20
• Housing Material: High-impact plastic
• Application: Indoor, workshop, garage, light outdoor use (protected from elements)
• Cable Insulation Material: PVC
• Cable Sheath Material: PVC
• Certification: CE
• Mounting: Freestanding, integrated handle for portability
• Color: Black/Orange

Tips

Always fully unwind the cable when using high-power devices to prevent overheating and ensure the thermal cut-out does not trip unnecessarily. For best longevity, store the reel in a dry, protected area when not in use.
