AJAX MotionCam Outdoor Detector de movimiento inalámbrico con verificación fotográfica, Black (PhOD)

The AJAX MotionCam Outdoor is a wireless PIR motion detector with photo verification, designed for reliable outdoor security. It combines a passive infrared sensor with a built-in camera to capture photo series upon alarm, reducing false alarms and providing visual confirmation of events. The detector supports Jeweller and Wings radio protocols for stable communication up to 1700 meters in open space.

Advantages

Photo verification with up to 5 photos per alarm; pet immunity up to 80 cm height and 20 kg weight; IP55 weatherproof rating; tamper protection and jamming detection; long battery life up to 3 years.

Suitable for

• Outdoor perimeter protection
• Residential and commercial security systems
• Integration with Ajax security hubs

Key specifications

• Detection type: PIR motion sensor with photo verification
• Installation environment: Outdoor
• Connectivity: Wireless (Jeweller & Wings)
• Motion detection range: Up to 15 m
• Motion detection angle: 90° horizontal, 80° vertical
• Camera resolution: Up to 640x480 pixels (VGA)
• Photo series: 1 to 5 photos (configurable)
• Photo on Demand (PhOD): Yes
• Night vision: IR illumination
• Pet immunity: Up to 80 cm / 20 kg
• Communication range: Up to 1700 m (open space)
• Frequency band: 868.0 – 868.6 MHz
• Power supply: 4 x CR123A batteries
• Battery life: Up to 3 years
• Operating temperature: -25°C to +60°C
• Operating humidity: Up to 95%
• Protection rating: IP55
• Anti-sabotage: Tamper protection, jamming detection
• Color: Black
• Compatibility: Ajax Hub 2, Hub 2 Plus, Hub 2 (4G), Hub 2 Plus (4G)

Recommendations

For optimal performance, install the detector at a height of 2.4 m and avoid direct sunlight or heat sources. Use only recommended CR123A batteries. Pair with an Ajax hub for full functionality.
