Akyga EN2010-1-F filtro EMC monofásico, 1 A, 120-250 V AC, 50/60 Hz, conector plano de 6,3 mm

The Akyga EN2010-1-F is a single phase EMI filter designed for low-current equipment where precision and reliability are essential. With a maximum operating current of 1 A, it is suitable for sensitive electronic systems such as measuring equipment, laboratory equipment, and automation components.

Key features

• Maximum working current: 1 A
• Leads: 6.3 mm connectors
• Leakage current: 0.43 mA @ 120 VAC 60 Hz, 0.74 mA @ 250 VAC 50 Hz
• Number of poles: 2
• Metal housing
• Operating temperature: -25°C to +100°C
• CE, RoHS, and REACH compatibility

Specifications

• Brand: Akyga
• MPN: EN2010-1-F
• Product type: EMI Filter
• Filter type: Anti-interference
• Product size (L x W x H): 61 x 56 x 22 mm
• EAN code: 5901720138415
