ALLNET ALL-BRICK-0036 Módulo convertidor DC/DC 7-24V entrada 5V 3A salida

The ALLNET ALL-BRICK-0036 is a high-efficiency DC/DC converter module designed to step down input voltages from 7V to 24V to a stable 5V output, delivering up to 3A of current. Ideal for embedded systems, IoT devices, and industrial applications, this compact module offers reliable power conversion with over 90% efficiency and comprehensive protection features.

Advantages

With a wide input voltage range, high efficiency, and built-in protections (overcurrent, overtemperature, short circuit), the ALL-BRICK-0036 ensures safe and stable power delivery. Its small footprint and through-hole mounting make it easy to integrate into various designs.

Suitable for

• Embedded electronics and microcontroller projects
• IoT devices and sensors
• Industrial control systems
• Battery-powered equipment requiring regulated 5V

Key specifications

• Input Voltage: 7V - 24V DC
• Output Voltage: 5V DC
• Output Current: 3A max
• Output Power: 15W max
• Efficiency: >90%
• Switching Frequency: Up to 1 MHz
• Operating Temperature: -40°C to +85°C
• Protection: OCP, OTP, SCP
• Ripple & Noise: <50mVp-p
• Line Regulation: ±0.5%
• Load Regulation: ±1%
• Quiescent Current: <10mA
• Mounting: Through-hole / Solder pads

Recommendations

For best performance, ensure adequate input capacitance and proper heat dissipation. This module is non-isolated; verify system grounding requirements.
