ALLNET ALL-BRICK-0328 módulo de alimentación para placas de desarrollo

The ALLNET ALL-BRICK-0328 is a versatile power supply module designed for development boards, breadboards, and prototyping systems. It provides stable 5V and 3.3V outputs, making it ideal for powering microcontrollers, sensors, and IoT devices.

Advantages

This module offers dual output voltages (5V and 3.3V) with up to 700mA each, ensuring reliable power for your projects. Its compact design and breadboard-compatible pin headers allow easy integration into existing setups. Built-in short circuit and overcurrent protection safeguard your components.

Suitable for

• ALL-BRICK System modules
• Breadboard prototyping
• Embedded systems and IoT devices
• Microcontroller power supply

Key specifications

• Input Voltage: 6.5V - 12V DC
• Output 1: 5V DC, 700mA max
• Output 2: 3.3V DC, 700mA max
• Input Connector: DC Jack (5.5mm x 2.1mm)
• Output Connector: 2.54mm pin headers
• Protection: Short circuit, overcurrent
• Operating Temperature: -20°C to +70°C

Recommendations

Use with an external DC adapter (not included) for best performance. Ideal for powering Arduino, ESP, and other development boards.
