ALPEN-MAYKESTAG Alpen Sprint Master TM 13/2 Broca helicoidal 13 mm HSS-G DIN 338

The ALPEN-MAYKESTAG Alpen Sprint Master TM 13/2 is a high-performance twist drill bit designed for professional drilling applications. Manufactured from premium HSS-G (High Speed Steel - Ground) material, this drill bit offers exceptional durability and precision. With a diameter of 13.0 mm and a total length of 151 mm, it is ideal for general purpose drilling in a variety of materials including steel, cast steel, grey cast iron, non-ferrous metals, and plastics.

Advantages

This drill bit features a 135° split point design that ensures self-centering and reduces feed pressure, making drilling easier and more accurate. The bright surface finish and ground from solid manufacturing process provide excellent chip removal and a long tool life. The DIN 338 standard guarantees compatibility and reliability.

Suitable for

• Steel and cast steel
• Grey cast iron
• Non-ferrous metals
• Plastics
• General purpose drilling applications

Key specifications

• Brand: ALPEN-MAYKESTAG
• Model: Alpen Sprint Master TM 13/2
• EAN: 9002741226061
• Drill Bit Type: Twist Drill Bit
• Diameter: 13.0 mm
• Total Length: 151 mm
• Working Length: 101 mm
• Material: HSS-G (High Speed Steel - Ground)
• Standard: DIN 338
• Shank Type: Cylindrical
• Point Angle: 135°
• Point Grind: Split Point (Cross-ground)
• Surface Finish: Bright
• Tolerance: h8
• Self-Centering: Yes
• Reduced Feed Pressure: Yes
• Recommended Material Hardness: Up to 900 N/mm²

Recommendations

For optimal results, use appropriate cutting speeds and feeds. Ensure the workpiece is securely clamped. Always wear safety goggles when drilling.
