Altavoz de 2 vías Omnitronic 11036960 150 W

The Omnitronic 11036960 is a 2-way wired loudspeaker delivering up to 150 W RMS in a weatherproof (IP54) plastic cabinet. Designed for both indoor and outdoor use, it covers a frequency range of 60–18,000 Hz with 94 dB sensitivity and is available in low-impedance (16 Ω) and 100 V transformer versions. The compact black housing fits bars, restaurants, shops and conference areas where reliable, balanced sound is required.

Advantages

The speaker offers reliable, balanced audio reproduction with a wide frequency response and good sensitivity for clear sound at moderate power levels. Weatherproof construction allows outdoor installation while the included rotatable mounting bracket supports flexible aiming. Availability in low-ohm and 100 V variants enables use in small single-speaker installations as well as larger distributed systems.

Suitable for

Key specifications

How to use

Mount the speaker using the included rotatable bracket and aim it toward the listening area. Connect the speaker with appropriate gauge wired speaker cable to the amplifier or a 100 V line depending on the chosen model. Adjust amplifier gain and any equalization to achieve balanced sound without clipping. For outdoor installations ensure the cabinet is mounted under partial cover or positioned to minimize direct exposure to driving rain despite the IP54 rating.

Recommendations

Use the low-impedance (16 Ω) model for single or small multi-speaker setups driven by conventional amplifiers; choose the 100 V version for larger distributed systems. Keep amplifier output within the 150 W RMS rating to avoid damage and preserve long-term performance.
