Altavoz de techo/instalación Omnitronic ODX-212T 100V, blanco

The Omnitronic ODX-212T 100V ceiling/installation loudspeaker in white is designed for permanent public-address and background-music installations. It is a flush-mounted ceiling speaker optimized for integration into commercial or institutional spaces where distributed audio over 100V lines is required. The speaker provides practical coverage for paging, ambient music and voice announcements while maintaining a discreet appearance that blends with typical ceiling finishes.

Advantages

The omnidirectional dispersion and 100V compatibility enable easy connection to multi-zone systems and long cable runs without significant power loss. Its white finish and low-profile grille offer unobtrusive installation in offices, retail areas or corridors. The speaker is built for fixed installation with mounting features suitable for standard ceiling cutouts, delivering consistent sound for speech intelligibility and background music playback.

Suitable for

Key specifications

How to use

Prepare the ceiling cutout according to the speaker's dimensions and secure the speaker into the mounting aperture following the manufacturer's mechanical instructions. Connect the speaker to the 100V line using the appropriate transformer taps or termination points provided for level selection. Verify polarity and secure wiring connections, then test playback with voice and music material to adjust system level and equalization from the central amplifier or matrix prior to finalizing the installation.

Recommendations

Install the ceiling loudspeaker at recommended spacing for even coverage and avoid mounting directly above high-noise equipment. Use suitable transformer tap settings to match room size and purpose: lower taps for background music to maintain comfortable levels and higher taps where clear paging is required. Regularly inspect wiring and grille for dust and secure fitment to ensure long-term reliable performance.
