Antec NE850P EC fuente de alimentación 850W - fuente de alimentación para PC/servidor

The Antec NE850P EC is a high-performance 850W power supply designed for demanding PC and server builds. With 80 PLUS Gold certification and fully modular cabling, it delivers efficient, reliable power with excellent cable management. The 120mm fluid dynamic bearing fan ensures quiet and durable cooling, while comprehensive protection features safeguard your components.

Advantages

80 PLUS Gold efficiency reduces energy waste and heat output. Fully modular design allows you to use only the cables you need, improving airflow and simplifying installation. The 120mm FDB fan offers a balance of low noise and long lifespan. Active PFC ensures stable operation across a wide input voltage range.

Suitable for

• High-end gaming PCs
• Workstations and servers
• Content creation systems
• Multi-GPU setups

Key specifications

• Total Power: 850W
• Efficiency: 80 PLUS Gold
• Modularity: Fully Modular
• Form Factor: ATX
• Fan Size: 120mm
• Fan Bearing: Fluid Dynamic Bearing (FDB)
• Input Voltage: 100-240 VAC
• Input Frequency: 50-60 Hz
• ATX Connector: 1x 24-pin
• EPS/CPU Connectors: 2x 8-pin (4+4)
• PCIe Connectors: 6x 8-pin (6+2)
• SATA Connectors: 10x
• Peripheral (Molex) Connectors: 5x
• Protection Features: OCP, OVP, UVP, SCP, OPP, OTP, NLO, SIP
• MTBF: 100,000 hours
• Operating Temperature: 0 - 40 °C
• Warranty: 7 Years

Recommendations

For optimal performance and longevity, pair this power supply with a high-quality UPS and ensure proper ventilation in your case. The fully modular design makes cable routing easy, even in compact cases.
