Armario de pared Extralink Extralink armario rack 15U 600x600 negro

Network administrators in small offices and CCTV control rooms often struggle with limited floor space while needing secure, organized housing for switches, patch panels, and DVRs. The Extralink EX.14343 solves this by mounting directly on the wall, freeing up valuable floor area and keeping equipment at a convenient height. Its 15U capacity accommodates a compact stack of networking gear, and the tempered glass front door allows quick visual checks without unlocking.

Key specifications

• Rack capacity: 15U
• External dimensions (H x W x D): 775 mm x 600 mm x 600 mm
• Material: cold-rolled steel (SPCC), 1.2 mm body, 2.0 mm mounting profiles
• Color: black (RAL9004)
• Front door: tempered glass, lockable, reversible hinge (left or right)
• Side panels: removable, lockable, tool-free snap fasteners
• Maximum static load: 60 kg
• Two fan cutouts on top panel for active cooling
• Cable entry: top and bottom with conduit for organized routing
• Adjustable vertical mounting rails with U-markings
• Protection rating: IP20
• Compliance: ANSI/EIA RS-310-D, IEC297-2, DIN41494 PART1, DIN41494 PART7

Why choose it

This cabinet combines robust steel construction with practical features that simplify installation and maintenance. The reversible glass door adapts to your room layout, while snap-fastener side panels allow quick access without tools. Lockable doors and panels deter unauthorized access, and the included keys provide basic physical security. With provision for two top fans and a cable conduit, you can maintain proper airflow and keep cables tidy, reducing the risk of overheating and simplifying troubleshooting.

Ideal use cases

• Small office network switches and patch panels
• Server room edge equipment and compact servers
• CCTV DVRs/NVRs and video transmission equipment
• IT closets and wall-mounted telecom installations
• Industrial control panels in limited-space environments

Good to know

The cabinet ships flat-packed to save on shipping volume and cost, and assembly is straightforward with the included mounting kit. It is designed for indoor use only (IP20). The adjustable rails support equipment with varying depths, making it versatile for different devices. Always verify wall structure and use appropriate anchors for the 60 kg load capacity.
