Avaya fuente de alimentación redundante (módulo plug-in) para Ethernet Routing Switch serie 5600

The Avaya Redundant Power Supply (Plug-In Module) is a high-performance power redundancy solution designed for the Avaya Ethernet Routing Switch 5600 Series. This plug-in module ensures uninterrupted network operation by providing backup power in the event of a primary power supply failure. Ideal for enterprise environments requiring maximum uptime, this hot-swappable module supports a wide range of switch models including the ERS 5632FD, 5650TD, 5650TD-PWR, 5698TFD, and 5698TFD-PWR.

Advantages

With its hot-swappable design, the Avaya redundant power supply can be replaced without powering down the switch, minimizing network downtime. The module delivers 600W of output power and supports input voltages from 100-240V AC, making it compatible with global power standards. Built-in protection features such as over-voltage, over-current, and short-circuit protection safeguard your network equipment.

Suitable for

• Enterprise data centers requiring high availability
• Network infrastructures using Avaya Ethernet Routing Switch 5600 Series
• Applications where power redundancy is critical for business continuity

Key specifications

• Device Type: Redundant Power Supply Module
• Form Factor: Plug-in module
• Power Redundancy: Yes
• Hot-Swappable: Yes
• Input Voltage: AC 100-240 V
• Input Frequency: 50/60 Hz
• Output Power: 600 W
• Compatibility: Avaya Ethernet Routing Switch 5600 Series
• Supported Switch Models: Avaya ERS 5632FD, 5650TD, 5650TD-PWR, 5698TFD, 5698TFD-PWR
• Status Indicators: Power LED, Fault LED
• Product Type: Power Supply
• Application: Network Infrastructure
• Installation: Internal slot
• Protection Features: Over-voltage, Over-current, Short-circuit protection

Recommendations

For optimal network reliability, pair this redundant power supply with compatible Avaya Ethernet Routing Switches. Ensure proper installation by a qualified technician to maximize performance and safety.
