AXING BVE 8-02 Splitter

The AXING BVE 8-02 is a splitter from AXING. It features high return loss attenuation and is optimized for multimedia services, with gold-plated signal pins.

Key features

• High return loss attenuation
• Splitter optimized for multimedia services
• Gold-plated signal pins

Specifications

• Brand: Axing
• Model: BVE 8-02
• Number of outputs: 8
• Attenuation at 40 MHz: 11 dB
• Attenuation at 470 MHz: 11 dB
• Attenuation at 862 MHz: 11.5 dB
• Attenuation at 1000 MHz: 12.0 dB
• Internal isolation at 40 MHz: 30 dB
• Internal isolation at 470 MHz: 30 dB
• Internal isolation at 862 MHz: 25 dB
• Internal isolation at 1000 MHz: 22 dB
• Return loss attenuation from input at 40 MHz: 18 dB
• Return loss attenuation from input at 470 MHz: 20 dB
• Return loss attenuation from input at 862 MHz: 20 dB
• Return loss attenuation from input at 1000 MHz: 20 dB
• Return loss attenuation from output at 40 MHz: 18 dB
• Return loss attenuation from output at 470 MHz: 20 dB
• Return loss attenuation from output at 862 MHz: 18 dB
• Return loss attenuation from output at 1000 MHz: 18 dB
• Dimensions: 142 x 64 x 32 mm
