BCS-AVC24/1205/ISO Fuente de alimentación CCTV 24V AC 5A 120W para montaje en carril DIN

Delivering a robust 120 W of clean, regulated AC power, the BCS-AVC24/1205/ISO is a professional-grade AC/AC transformer engineered for CCTV and security installations that demand unwavering reliability. Its 24 V AC output at 5 A ensures stable operation for multiple cameras, IR illuminators, and access control devices, while the integrated overload, short-circuit, and overvoltage protections safeguard your entire system.

Overview

Built around a high-efficiency toroidal transformer, this DIN rail mountable unit converts 230 V AC mains input (50/60 Hz) to a safe, isolated 24 V AC output. The galvanic isolation between input and output eliminates ground loop interference, a common cause of video distortion in surveillance setups. The rugged metal enclosure with IP20 rating is designed for indoor electrical cabinets, providing passive convection cooling for silent, maintenance-free operation.

What stands out

• High power density: 120 W continuous output in a compact DIN rail housing.
• Comprehensive protection: overload, short-circuit, and overvoltage safeguards prevent damage to connected equipment.
• Electrical isolation: input/output isolation prevents ground loops and enhances safety.
• Wide operating temperature range: -10°C to +40°C for reliable performance in diverse environments.
• Passive cooling: no fans or moving parts, ensuring silent operation and long service life.
• DIN rail mounting: quick and secure installation in standard distribution boards.

Technical details

• Input voltage: 230 V AC, 50/60 Hz
• Output voltage: 24 V AC
• Output current: 5 A
• Output power: 120 W
• Number of outputs: 1
• Mounting method: DIN rail
• Protection features: overload, short-circuit, overvoltage
• Enclosure rating: IP20
• Enclosure material: metal
• Operating temperature range: -10°C to +40°C
• Cooling type: passive (convection)
• Primary application: CCTV cameras, security systems
• Electrical isolation: yes (input/output)

Our verdict

The BCS-AVC24/1205/ISO is a workhorse power supply that delivers consistent, protected AC power for professional security installations. Its isolation, robust protection, and DIN rail design make it a dependable choice for integrators and installers who refuse to compromise on system uptime.
