BCS BCS-L-AR Cámara exterior tipo bala 2MP 1080p Full HD con salida de vídeo 4 en 1 (AHD/TVI/CVI/CVBS), distancia focal fija 2,8mm, ángulo de visión 103°, IR hasta 20m, carcasa metálica IP66, DC 12V

The BCS-L-AR from BCS stands out with its 4-in-1 video output, supporting AHD, TVI, CVI, and CVBS signals over coaxial cable, making it a versatile choice for upgrading legacy surveillance systems without replacing existing wiring. Its 2-megapixel CMOS sensor delivers crisp 1080p Full HD video at 25/30 fps, while the 2.8mm fixed lens provides a wide 103° horizontal field of view to cover more area with a single camera.

Highlights

• 2MP 1/2.7" CMOS sensor with 1920x1080 resolution
• 4-in-1 video output: AHD / TVI / CVI / CVBS
• 2.8mm fixed lens with approx. 103° horizontal viewing angle
• IR illumination up to 20m with ICR day/night switching
• IP66-rated metal housing for outdoor use

In daily use

This bullet camera is built for reliable 24/7 monitoring. With a minimum illumination of 0.01 lux in color mode and 0 lux with IR on, it captures clear images even in low light. The built-in ICR filter automatically switches between day and night modes, while 2DNR and DWDR enhance image quality in challenging lighting. On-screen display (OSD) can be controlled via coaxial connection for easy setup. Powered by a standard DC 12V supply, the camera consumes a maximum of 3W with IR active, ensuring energy efficiency.

Full specifications

• Sensor: 1/2.7" CMOS, 2MP (1920x1080)
• Video output: AHD / TVI / CVI / CVBS (4-in-1)
• Lens: 2.8mm fixed, horizontal viewing angle approx. 103°
• IR range: up to 20m, ICR day/night
• Minimum illumination: 0.01 lux (color), 0 lux (IR on)
• Noise reduction: 2DNR; WDR: DWDR
• OSD: Yes, coaxial control
• Power: DC 12V, max 3W with IR
• Ingress protection: IP66
• Housing: Metal
• Operating temperature: -30°C to +60°C

Final note

The BCS-L-AR combines multi-format compatibility with durable outdoor construction, making it a practical choice for both new and retrofit installations.
