BCS Inyector PoE 30W Gigabit IEEE 802.3af/at

The BCS-P-LSIPO30 is a high-performance Power over Ethernet (PoE) injector designed to deliver up to 30W of power and Gigabit data over a single Ethernet cable. Compliant with IEEE 802.3af/at standards, it provides a reliable and cost-effective solution for powering PoE-enabled devices such as IP cameras, wireless access points, and VoIP phones. Its compact ABS plastic housing supports desktop and wall-mountable installation, making it ideal for both home and office environments.

Advantages

This PoE injector simplifies network setup by eliminating the need for separate power cables near devices. With auto-sensing Mode A/B compatibility, it works seamlessly with a wide range of PoE devices. The unit features robust protection against overload, short circuits, and over-voltage, ensuring safe and stable operation. Its energy-efficient design consumes less than 2W in idle mode, reducing overall power costs.

Suitable for

• IP cameras (indoor/outdoor)
• Wireless access points (WAPs)
• VoIP phones
• Network extenders and IoT devices

Key specifications

• PoE Standard: IEEE 802.3af/at
• Max. PoE Power Output: 30 W
• PoE Output Voltage: 52 V DC
• Data Transfer Rate: 10/100/1000 Mbps (Gigabit Ethernet)
• Ethernet Ports: 1x Data In (RJ45), 1x PoE Out (RJ45)
• Input Voltage: 100-240 V AC, 50/60 Hz
• Power Pin Assignment: Auto-sensing (Mode A/B compatible)
• LED Indicators: Power, PoE Status
• Operating Temperature: -10°C to 45°C
• Storage Temperature: -20°C to 70°C
• Operating Humidity: 5% to 90% RH (non-condensing)
• Protection Features: Overload, Short Circuit, Over-voltage
• Housing Material: ABS Plastic
• Power Consumption (Idle): < 2 W
• Power Efficiency: > 80%
• Installation: Desktop, Wall-mountable

Recommendations

For optimal performance, use with IEEE 802.3af/at compliant devices. Ensure proper ventilation when mounting on walls. The injector is compatible with standard Cat5e or higher Ethernet cables.
