BCS Lector de códigos de barras 2D fijo lector de códigos industrial RS232 RS485 USB IP65

The BCS-L-CRS-M7Z is a compact industrial code reader designed for high-performance barcode scanning in demanding environments. Featuring a CMOS area imager with VGA resolution, it reliably reads both 1D and 2D barcodes, including QR Code, Data Matrix, and PDF417. With an IP65 rating and aluminum alloy housing, this fixed-mount scanner is built to withstand dust, water, and harsh industrial conditions.

Advantages

This code reader offers versatile connectivity options (RS232, RS485, USB) and a fast scan rate of up to 60 frames per second, ensuring efficient data capture. Its compact design with M3 threaded holes allows easy integration into automated systems. The red LED illumination and support for small barcodes (4 mil 1D, 6 mil 2D) make it suitable for high-precision applications.

Suitable for

• Industrial automation and production lines
• Logistics and warehouse management
• Quality control and traceability
• Embedded barcode reading in machinery

Key specifications

• Reading Technology: CMOS Area Imager (2D)
• Sensor Resolution: 640 x 480 pixels (VGA)
• Supported 1D Symbologies: Code 128, Code 39, EAN-13, EAN-8, UPC-A, UPC-E, Interleaved 2 of 5, Code 93, Codabar, GS1 DataBar
• Supported 2D Symbologies: QR Code, Data Matrix, PDF417, Aztec Code, MaxiCode
• Minimum Element Size (1D): 0.1 mm (4 mil)
• Minimum Element Size (2D): 0.15 mm (6 mil)
• Reading Distance: 20 - 150 mm (code dependent)
• Scan Rate: Up to 60 frames/second
• Interface: RS232, RS485, USB
• Illumination: Red LED
• IP Rating: IP65
• Operating Temperature: -10°C to +50°C
• Power Supply: 5V DC (USB) / 5-24V DC (External)
• Housing Material: Aluminum Alloy
• Mounting Type: M3 Threaded Holes
• Configuration Method: Software (BCS Configurator)
• Output Data Format: ASCII

Recommendations

For optimal performance, use the BCS Configurator software to adjust settings and integrate the scanner into your system. Ensure proper mounting and cable connections to maintain IP65 protection.
