BCS-RA2-N Estación exterior 2MP 1080p IP65 IK07 Plata

The BCS-RA2-N is a high-quality outdoor access control panel designed for the BCS 2-wire system. Featuring a 2 Megapixel (1080p) camera with IR night vision up to 3m, two-way audio, and a durable aluminum alloy front panel with IP65 and IK07 ratings, it is ideal for secure entry in residential and commercial buildings.

Advantages

Reliable 2MP camera ensures clear video identification. Two-way audio allows communication with visitors. Robust construction with IP65 weatherproofing and IK07 vandal resistance ensures long-lasting performance. Easy surface mount installation and powered via the BCS 2-wire system.

Suitable for

• Apartment buildings
• Office complexes
• Gated communities
• Secure facility entrances

Key specifications

• Camera Resolution: 2 Megapixel (1080p)
• Image Sensor: 1/2.8" CMOS
• Viewing Angle: 100° (H) x 54° (V)
• Night Vision: IR LED, up to 3m
• Audio: Two-way audio with built-in microphone and speaker
• Call Buttons: 1
• Material: Aluminum alloy (front panel)
• Ingress Protection: IP65
• Vandal Resistance: IK07
• Mounting: Surface mount
• Power Supply: 2-wire system (powered by BCS-RA2-PS)
• Operating Temperature: -30°C to +60°C
• Door Lock Relay: 1
• Connectivity: BCS 2-Wire System
• Color: Silver/Grey

Recommendations

For optimal performance, pair with the BCS-RA2-PS power supply and compatible BCS indoor stations. Ensure proper surface mounting for weather sealing.
