Biamp Cambridge E-A-W-16-4 Procesador de cancelación de eco acústico

The Biamp Cambridge E-A-W-16-4 is a high-performance Acoustic Echo Cancellation (AEC) processor designed for professional audio conferencing and collaboration environments. With 16 AEC channels and 4 non-AEC channels, it delivers crystal-clear audio by eliminating echo and background noise, ensuring natural and intelligible communication. This half-rack, 1U device integrates seamlessly into existing AV systems via Dante network audio and offers flexible analog I/O connectivity.

Advantages

Enhanced audio clarity with 128 ms AEC tail length, automatic gain control, and noise reduction. Low processing latency (<10 ms) ensures real-time performance. Compact half-rack design saves space. Compatible with Biamp SageVue and TesiraFORTÉ for easy system integration and management.

Suitable for

• Conference rooms and boardrooms
• Distance learning and lecture halls
• Video conferencing systems
• Collaborative workspaces

Key specifications

• Product Type: Acoustic Echo Cancellation (AEC) Processor
• AEC Channels: 16
• Non-AEC Channels: 4
• Analog Inputs: 16 Mic/Line, 4 Line
• Analog Outputs: 4 Line
• Network Audio: Dante
• Sampling Rate: 48 kHz
• Frequency Response: 20 Hz - 20 kHz
• Dynamic Range: >100 dB
• Processing Latency: <10 ms
• Control Interface: Ethernet (RJ-45), RS-232
• Connectors: Phoenix (Analog I/O), RJ-45 (Ethernet/Dante)
• Mounting: Half-rack, 1U
• Power Supply: External 24V DC

Recommendations

For optimal performance, pair with Biamp TesiraFORTÉ or SageVue software for advanced configuration and monitoring. Ensure proper microphone placement and acoustic treatment for best echo cancellation results.
