BlueOptics Cable de cobre de conexión directa pasivo QSFP28 100G 5m negro

The BlueOptics 100G-QSFP-QSFP-P-5M-BL is a high-performance passive direct attach copper (DAC) cable designed for 100 Gigabit Ethernet and InfiniBand EDR applications. With QSFP28 connectors on both ends and a length of 5 meters, this black cable provides reliable, low-latency connectivity for data centers and high-performance computing environments.

Advantages

This cable offers ultra-low power consumption (typically less than 0.5W per end) and hot-pluggable capability, making it an energy-efficient and convenient solution for high-speed interconnects. Its passive design ensures cost-effectiveness without compromising performance.

Suitable for

• Data center top-of-rack to server connections
• High-performance computing (HPC) clusters
• Enterprise networking with 100GbE or InfiniBand EDR

Key specifications

• Product Type: InfiniBand Cable
• Cable Type: Direct Attach Copper (DAC)
• Connector Type (End 1): QSFP28
• Connector Type (End 2): QSFP28
• Data Rate: 100 Gbps
• InfiniBand Protocol: EDR (Enhanced Data Rate)
• Ethernet Protocol: 100 Gigabit Ethernet (100GbE)
• Cable Length: 5 meters
• Cable Technology: Passive
• Color: Black
• Hot-Pluggable: Yes
• MSA Compliance: SFF-8665 (QSFP28 Multi-Source Agreement)
• Power Consumption: Ultra-low (typically < 0.5W per end)
• Impedance: 100 Ohm

Recommendations

For optimal performance, ensure that both network devices support QSFP28 interfaces and 100G standards. This cable is compatible with a wide range of switches, routers, and servers from major vendors.
