Módulo SFP CBO ABCU-5740RZ-BC-BO, 1250 Mbit/s, 100 m

Single‑mode SFP transceiver BlueOptics CBO ABCU-5740RZ-BC-BO delivers a 1250 Mbit/s data rate over optical fiber with a reach of up to 100 m. The small form‑factor pluggable module is designed for hot‑swappable insertion into compatible switches, routers and media converters, providing a standardized electrical and optical interface for short‑distance fiber links in LAN environments. It supports single‑mode fiber links where compact, reliable optical connectivity is required and conforms to typical SFP physical and electrical characteristics used in network equipment.

Advantages

The transceiver offers a compact, hot‑swappable SFP form factor that simplifies installation and replacement without powering down equipment. Its single‑mode optical design and 1250 Mbit/s capability ensure compatibility with common 1 Gbps network ports operating over fiber, while the 100 m reach covers short backbone and device-to-device connections within buildings or campus networks. Standardized interface characteristics support interoperability with a wide range of network devices from different manufacturers.

Suitable for

• Short-distance fiber links between switches and routers within LANs
• Connections to media converters and fiber-enabled network ports
• Device-to-device optical links in server rooms and campus environments
• Upgrading copper ports to fiber where single‑mode connectivity is required

Key specifications

• Form factor: SFP (Small Form‑Factor Pluggable)
• Optical mode: Single‑mode
• Data rate: 1250 Mbit/s
• Maximum reach: up to 100 m over single‑mode fiber
• Connector type: LC duplex compatible
• Hot‑swappable: yes
• Typical application: short‑distance LAN fiber links

How to use

Insert the SFP module into a compatible SFP slot on the switch, router or media converter until it clicks into place. Connect single‑mode fiber patch cables to the module’s LC duplex connector, observing correct transmit/receive orientation. Verify link and port status on the host device and configure interface settings such as speed and duplex if required by the network equipment. To remove, disengage any retention mechanism and pull the module straight out while the device remains powered off or follow the host device’s hot‑swap guidance.

Recommendations

Use single‑mode fiber patch cables with appropriate attenuation and LC duplex connectors. Avoid bending the fiber beyond its minimum bend radius and keep dust caps on the transceiver when not in use. Confirm compatibility with the host device and ensure firmware or port settings match the transceiver’s data rate and optical characteristics for reliable operation.
