BlueOptics QSFP-LX4-40G transceptor QSFP compatible con Quanta, 40GBASE-LX4, 1310nm, 10km, LC dúplex, monomodo

The BlueOptics QSFP-LX4-40G-BO is a compatible transceiver engineered for Quanta QSFP-LX4-40G switches and routers, delivering 40 Gigabit Ethernet over single-mode fiber. Unlike generic QSFP modules, it supports 40GBASE-LX4 with a 1310 nm wavelength and reaches up to 10 km on LC duplex connectors.

Highlights

• 40 Gbps data rate for high-speed networking
• QSFP form factor with hot-swappable design
• Supports 40 Gigabit Ethernet, Fibre Channel, and SONET/SDH
• Digital Diagnostics Monitoring (DDM/DOM) for real-time status
• DFB laser for reliable single-mode transmission

In daily use

Deploy this transceiver in data centers, enterprise networks, or storage systems where long-distance connectivity is required. Its low power consumption of under 2.5 W and operating temperature range from 0°C to 70°C ensure stable performance in demanding environments. The LC duplex interface simplifies fiber management.

Full specifications

• Form Factor: QSFP
• Data Rate: 40 Gbps
• Standard: 40GBASE-LX4
• Wavelength: 1310 nm
• Maximum Transfer Distance: 10 km
• Fiber Type: Single-mode
• Connector Type: LC Duplex
• DDM/DOM Support: Yes
• Hot-Plug Support: Yes
• Power Consumption: < 2.5 W
• Operating Temperature: 0°C to 70°C
• Laser Type: DFB

Final note

BlueOptics transceivers are tested for compatibility with Quanta equipment, providing a cost-effective alternative without sacrificing performance or reliability.
