BlueOptics Ruckus 100G-QSFP-QSFP-P-0201 Cable DAC QSFP28 BlueLAN compatible 2m negro

The BlueOptics Ruckus 100G-QSFP-QSFP-P-0201 compatible BlueLAN DAC QSFP28 Cable is a high-performance direct attach copper (DAC) cable designed for 100 Gigabit Ethernet applications. It provides a reliable and cost-effective solution for short-range interconnects in data centers and enterprise networks.

Advantages

This passive twinax cable offers low power consumption (<0.1W) and hot-swappable functionality, ensuring minimal downtime and easy installation. With a length of 2 meters and 26 AWG wire gauge, it delivers excellent signal integrity and flexibility for rack-to-rack or rack-internal connections.

Suitable for

• Data Center Interconnects
• High-Performance Computing (HPC)
• Enterprise Networking
• Ruckus 100G-QSFP-QSFP-P-0201 compatible equipment

Key specifications

• Data Transfer Rate: 100 Gbps
• Cable Type: Direct Attach Copper (DAC)
• Connector Type: QSFP28 to QSFP28
• Cable Length: 2 meters (6.56 ft)
• Transceiver Type: Passive Twinax
• AWG: 26 AWG
• Impedance: 100 Ohm
• Operating Temperature: 0°C to 70°C
• Storage Temperature: -40°C to 85°C
• Power Consumption: < 0.1W
• Jacket Material: PVC
• Color: Black
• Minimum Bend Radius: 25 mm
• Certifications: RoHS, CE, FCC

Recommendations

This cable is ideal for high-speed data transmission within racks and between adjacent racks. Ensure compatibility with your QSFP28 ports. For optimal performance, avoid sharp bends and maintain proper cable management.
