Transceptor CBO AX-F6244-3S1LX-BO módulo de fibra óptica 3S1LX para Alaxala Networks

CBO AX-F6244-3S1LX-BO is a fiber optic transceiver module designed for compatibility with Alaxala Networks equipment. The 3S1LX single-fiber module supports optical data transmission and fits standard SFP/slot interfaces in switches and routers. It is intended for use when extending network links, replacing defective modules, or upgrading existing copper links to fiber in enterprise and carrier-grade environments.

Advantages

The module offers reliable optical connectivity with form-factor compatibility for Alaxala devices and other platforms that accept the same transceiver type. It provides stable signal transmission over single-fiber links and supports straightforward hot-swap replacement in operational network equipment. The compact SFP-compatible design reduces space requirements and facilitates easy deployment in dense rack environments.

Suitable for

• Extending network links between switches and routers over fiber
• Replacing damaged or obsolete transceiver modules in Alaxala-compatible equipment
• Upgrading copper-based links to fiber for improved distance and interference immunity
• Carrier, data center and enterprise network uplinks requiring single-fiber connections

Key specifications

• Transceiver type: single-fiber optical module compatible with SFP-sized slots
• Operating mode: optical transmit and receive over a single fiber (bidirectional)
• Application: network uplinks and point-to-point fiber links
• Form factor: compact module suitable for high-density switch/router slots
• Environment: designed for enterprise and carrier networking scenarios

How to use

Install the module into a compatible transceiver slot on the Alaxala Networks switch or router while the device is powered on or following the vendor's hot-swap guidance. Connect the single-fiber patch cable using the appropriate connector type for the module, then verify link status in the device management interface. For replacement, remove the existing module carefully by releasing any retention mechanism before inserting the new unit. Observe standard electrostatic discharge precautions and follow the host device's documentation for any software or configuration steps required to recognize the new optical interface.

Recommendations

Use manufacturer-recommended fiber patch cords and connectors, keep connectors clean to maintain optimal signal quality, and validate link parameters after installation. For long-distance or critical links, perform end-to-end testing with an optical power meter or appropriate diagnostics and ensure firmware and device settings match required data rates and modes.
